K-Series Liquid Ring Vacuum Pumps and Compressors
KAKATI has been manufacturing liquid ring vacuum pumps since 50 years and has been constantly upgrading it’s design. An upgrade to it’s KV-Series, these pumps can run with wide range of operating speeds. This enables the user to save energy by running the pumps at lower speeds. It also provides a wide margin for future capacity increase by running the pump at higher operating speeds.
These pumps are available in 8 models and can handle excess liquid carryover without much difficulty. These pumps can be used in many applications like textile, mining, paper, sugar, tobacco, food, and other process industries.
The K-Series Vacuum Pumps have been designed for easy dismantling and overhauling to facilitate quick service. Like all KAKATI Vacuum Pumps, the K-Series Vacuum Pumps require very little care or maintenance in most applications
Basic specification
| S.No | Specification | Description |
|---|---|---|
| 1 | Vacuum range | Upto 710 mmHg |
| 2 | Capacity | Upto 22500 m3/hr |
| 3 | Compressor pressure | 2 bar abs |
| 4 | Standard Construction material | Cast iron, Stainless Steel |
